Description & Details
Datalogic QuickScan Lite QW2100 DescriptionThe QuickScan reader series is Datalogic ADCs value line of
general purpose handheld data collection products. The QuickScan
Lite QW2100 linear imager is an entry level product created
specifically for reading long and truncated bar codes which is
common in some areas of the world. It is perfect for use in retail,
light manufacturing, document/bill processing and banking/finance
environments.
The QW2100 imager is small, lightweight and its ergonomic design is
comfortable to use during daily operations. It offers snappy
reading performance on most 1D bar codes and features a wide
scanning angle with an extended scanning line which is perfect for
capturing longer and wider bar codes typically found on utility
bills and used by manufacturers of electronic parts. Additionally,
the scanning line is thinner and brighter, allowing users to scan
at wide angles without having to increase the scanning
distance.
A specially designed stand has been created for the QW2100 imager
which is light in weight, collapsible to use as a holder instead of
a stand, and also has a tiltable head for various angle
settings.
The QW2100 imager is available with two interface options: USB or
Keyboard Wedge / RS-232 and includes various packaging options so
that it can be ordered as a scanner only or as a kit equipped with
a scanner, cable and stand to facilitate hands-free reading
options. The Datalogic Aladdin configuration software provides
user-friendly features that simplify the start-up procedure, even
for inexperienced users.
Because this imager was created for specific areas of the world,
please check with your Datalogic Representative to inquire if the
QW2100 imager is available in your area.
Features
– Wide scan angle
– Laser-like thinner and extended scan line
– Datalogics patented Green Spot technology for good-read
feedback
– Water and Particulate Sealing Rating: IP42
– Drop Resistance to 1.5 m / 5.0 ft
– Uses the same cables and power supplies as the current QuickScan
products
– Bulk packaging available (10 scanners per box)
– USB Certified Kits available
Scanning
Linear (1D) barcodes supported
EAN 5,EAN-13,EAN-8,GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported
Not supported
Yaw reading angle
-70 – 70°
Wavelength
650 nm
Tilt reading angle
-45 – 45°
Sensor type
Laser
Read rate (max)
400 reads/s
Pitch reading angle
-65 – 65°
Ports & interfaces
Connectivity technology
Wired
Interface
USB
Design
Type
Handheld
International Protection (IP) code
IP42
Colour of product
Black
Technical details
Type
Handheld
International Protection (IP) code
IP42
Colour of product
Black
Power
Power consumption
340 mA
Power source type
DC
Input voltage
5
Packaging data
Cables included
USB
Operational conditions
Storage temperature (T-T)
-40 – 70 °C
Operating temperature (T-T)
0 – 50 °C
Operating relative humidity (H-H)
5 – 95%
Weight & dimensions
Width
170 mm
Depth
65 mm
Height
70 mm
Weight
119 g
Packaging content
Cables included
USB
Details
OPC
P8QDJ2
Brand
Datalogic
Codes
5712505163245 (EAN)
